Model: USB-MSP430-FPA-STD
Manufacturer: Elprotronic Inc.
Description: Programmers – Processor Based FlashPro430 STD FOR TI MSP430 MCU
Elprotronic FlashPro430 Flash Programmer is designed to program the Texas Instruments MSP430 microcontrollers (MCUs). This Elprotronic programmer allows 60KB Flash to be erased, blank checked, programmed, and verified in 3.5 seconds via JTAG interface and in 6.3 seconds via BSL interfaces. Eight pieces of the MSP430 (60KB each) can be programmed simultaneously in 3 seconds using Multi-FPA API-DLL and eight USB-FPAs. The FlashPro430 allows designers to open/save a project with encryption and password protection and allows DCO calibration for any Fxx. This Elprotronic Flash Programmer also features automated DCO calibration and a self test program that allows designers to check programmer functionality with a customer’s fixture and target device.
Features:
– Embedded Flash programmer. USB-FPA hardware adapter runs with FlashPro-430 software.
– Programs Texas Instruments MSP430.
– Supports JTAG, SBW, and BSL communication.
– Power supply from adapter available, up to 200 mA.
– Customizable Vcc from 1.65 to 4.0V.
– IAR EW430 debugging support.
Datasheet
Type: Programmer (In-Circuit/In-System)
Interface Type: BSL, JTAG, SBW, USB
For Use With/Related Products: MCU
Operating Supply Voltage: 5V
Dimensions: 76 x 43 x 20mm
Unit Weight: 9.462769oz
