Model: UUD1H4R7MCL1GS
Manufacturer: Nichicon
Description: 4.7 µF 50 V Aluminum Electrolytic Capacitors Radial, Can – SMD 2000 Hrs @ 105°C
Capacitance: 4.7 µF
Tolerance: ±20%
Voltage – Rated: 50 V
Lifetime @ Temp.: 2000 Hrs @ 105°C
Operating Temperature: -55°C ~ 105°C
Polarization: Polar
Ratings: AEC-Q200
Ripple Current @ Low Frequency: 42.5 mA @ 120 Hz
Impedance: 1.52 Ohms
Size / Dimension: 0.197″ Dia (5.00mm)
Height – Seated (Max): 0.240″ (6.10mm)
Surface Mount Land Size: 0.209″ L x 0.209″ W (5.30mm x 5.30mm)
Mounting Type: Surface Mount
Package / Case: Radial, Can – SMD
